PRO TRADE SERIES TP96
The full-scale mobile workshop.
If you want the lot, the Pro Trade Series TP96 delivers. As the largest trailer in the range, it’s built for businesses that need maximum storage, maximum organisation, and the ability to roll onto site with everything in one place.
With outstanding storage capacity, additional tool drawers, and an inbuilt drop saw slide, the TP96 functions like a proper mobile workshop - suitable across a wide range of trades. If your work demands a setup that’s secure, highly mobile, and seriously efficient, the TP96 is one you should have on the shortlist.
$30,990 + GST
See Our Flexible Finance Options
NZ Wide Delivery
SEE THE TP96 IN ACTION
Take a closer look at the TP96 on the job — from its full-scale storage system and added tool drawers to the inbuilt drop saw slide that makes day-to-day work faster and smoother. Built to roll onto site with everything in one place.
Photo's may show optional extras
SPECIFICATIONS & TECHNICAL DETAILS
For those wanting more detailed information, you’ll find the full technical specifications, dimensions, running gear, and electrical details here. You’re welcome to download our brochure for a complete overview.
TRADE PRO SERIES TP96
TARE 1590kg (without options)
GVM 3200kg
PAYLOAD 1600kg
BALL WEIGHT 145kg (Dry)
SIZE 4810mm(L) x 2150mm(W) x 2150mm(H)
BODY SPECIFICATION
Heavy duty one-piece RHS chassis 100x50x4mm that’s fully hot dip galvanised and powder coated
Precision CNC laser cut and pressed zinc anneal body sheets
Duragal internal structure support framing
Top storage ladder rack with welded mesh on underside and rear roller 2700mm(L) x 1800mm(W)
Front draw bar load support rack
Aluminium stone protection plates and foot treads all round
Flush mount side and rear opening doors with automotive seals and gas struts
Central Locking whale tail handles
Fittings (bolts, nuts, washers, screws and pop rivets) are all stainless steel
RUNNING GEAR
8 leaf Rocket Roller suspension and solid 50mm square axles (rated 3.5 tonne)
Dual 12” electric brake hubs with 6 stud Land Cruiser stud pattern
5 x 15” alloy rims and tyres
Premium jockey wheel with rubber tyre
3,500kg tow coupling to suit 1 ⅞” ball with handbrake
STORAGE
Main body storage compartment internally is 2650(L) x 1740(W) x 960(H) with lift up doors either side
Enclosed front storage box with fridge slide, storage compartments & shelving. Fridge slide size: 850mm(L) x 550mm(W) x 530mm(H)
Storage rail system on top of front box for additional items to be carried
2 x rear shelving levels, Bottom: 400mm deep, Top: 350mm deep
2 x massive rear slide out drawers Left side: 1530mm(L) x 640mm(W) x 360mm(H) on 160kg rated slides Right side: 2120mm(L) x 640mm(W) x 360mm(H) on 160kg rated slides
2 x slide out drawers either side towards front of main body 850mm(L) x 290mm(W) x 220mm(H)
Inside is a large storage shelving platform on right side of trailer 600mm deep and full length
2 x toolbox style drawer systems on right side under shelf with large drawers
ELECTRICAL
Full LED internal lighting with control management panel in main body
2 x 120A/H batteries
50 Amp Anderson Plug for charging while driving or solar (connection only)
LED tail lights with reverse light, side marker and front clearance lights
Safety Breakaway Unit
Includes Elecbrake Controller
Central Locking to all doors with alarm system
ACCESSORIES & CUSTOMISATION
Customise your trailer to match how you work.
READY FOR A FULL-SCALE MOBILE WORKSHOP?
If you need maximum storage, maximum organisation, and a setup that keeps your tools secure while you work at speed, the TP96 delivers the space and efficiency to run your trade like a well-oiled machine.
